Oak 40 Spacesaver

The Oak 40 Space Saving Staircase

The Oak 40 Space Saving Staircase

If you are looking for quality the Oak 40 space saver staircase is the ultimate product available on the market today, previously the Oak 40 space saver has only been available as a bespoke staircase with bespoke pricing we are pleased to offer the Oak 40 availabe to order online with competitivly set pricing.

Oak 40 Spacesaver 12 Risers

Oak 40 Spacesaver 12 Risers

Ref: oak4012

Oak 40 Spacesaver Staircase.

This staircase will have 12 risers, the going dimension for this staircase is 1350mm.
Specification
Strings 40mm American White Oak
Treads 40mm American White Oak
Risers 9mm Oak faced Plywood

When ordering please select your rise height you can choose a height between 2300 and 2640mm
The Rise is the Floor to floor Height.

You can also select your width.

Typical delivery time on this is 3 weeks.

This staircase is made to the requirments set out in the UK Building Regulations document K for Alternating Tread Staircases.

(Please note the Oak will be laminated to achive the desired widths on this staircase)
(Please note the photograph shows the staircase with 15 risers the product you are ordering has 12 risers)
(Please note the photograph shows the staircase with carpet inserts - these are an optional extra)

Note - Please Note Treads on Alternating Tread Staircases require a Anti Slip Resistant Surface applying following installation - The Staircase is Not Supplied with any Anti Slip material and it is the responsability of the client to ensure this is carried out. Recomendations can be found in Document BS EN-15644 2008.


Price: £1,449.00 (Excluding VAT at 20%)


Oak 40 Spacesaver 13 Risers

Oak 40 Spacesaver 13 Risers

Ref: oak4013

Oak 40 Spacesaver Staircase.

This staircase will have 13 risers, the going dimension for this staircase is 1460mm.
Specification
Strings 40mm American White Oak
Treads 40mm American White Oak
Risers 9mm Oak faced Plywood

When ordering please select your rise height you can choose a height between 2500 and 2860mm
The Rise is the Floor to floor Height.

You can also select your width.

Typical delivery time on this is 3 weeks.

This staircase is made to the requirments set out in the UK Building Regulations document K for Alternating Tread Staircases.

(Please note the Oak will be laminated to achive the desired widths on this staircase)
(Please note the photograph shows the staircase with 15 risers the product you are ordering has 13 risers)
(Please note the photograph shows the staircase with carpet inserts - these are an optional extra)

Note - Please Note Treads on Alternating Tread Staircases require a Anti Slip Resistant Surface applying following installation - The Staircase is Not Supplied with any Anti Slip material and it is the responsability of the client to ensure this is carried out. Recomendations can be found in Document BS EN-15644 2008.


Price: £1,499.00 (Excluding VAT at 20%)


Oak 40 Spacesaver 14 Risers

Oak 40 Spacesaver 14 Risers

Ref: oak4014

Oak 40 Spacesaver Staircase.

This staircase will have 14 risers, the going dimension for this staircase is 1570mm.
Specification
Strings 40mm American White Oak
Treads 40mm American White Oak
Risers 9mm Oak faced Plywood

When ordering please select your rise height you can choose a height between 2700 and 3080mm
The Rise is the Floor to floor Height.

You can also select your width.

Typical delivery time on this is 3 weeks.

This staircase is made to the requirments set out in the UK Building Regulations document K for Alternating Tread Staircases.

(Please note the Oak will be laminated to achive the desired widths on this staircase)
(Please note the photograph shows the staircase with 15 risers the product you are ordering has 12 risers)
(Please note the photograph shows the staircase with carpet inserts - these are an optional extra)

Note - Please Note Treads on Alternating Tread Staircases require a Anti Slip Resistant Surface applying following installation - The Staircase is Not Supplied with any Anti Slip material and it is the responsability of the client to ensure this is carried out. Recomendations can be found in Document BS EN-15644 2008.


Price: £1,659.00 (Excluding VAT at 20%)


Carpet Inserts

Carpet Inserts

Ref: CARP

Carpet Inserts - This option includes recessing the treads for the carpet insert and the carpet insert, please select a colour from the list.

These are only available as an option When Purchasing a Beech 40, Birch 24 or Oak 40 Spacesaver.

The Carpet insert also acts as a Non-Slip on the tread as requested in the Building Regulations.

These colours are only a guide and cannot be classed as a acurate representation of the colour.


Price: £120.00 (Excluding VAT at 20%)

European Style Handrail to the Right hand side

European Style Handrail to the Right hand side

Ref: oak40hr-rh

On the Oak 40 Spacesaver The European Style handrail is Optional.

This option is for the right hand side if you are going up the staircase

Please note this can only be ordered when ordering a Oak 40 Spacesaver

Specification
Newel posts - American White Oak
Handrail - American White Oak
Balusters - Stainless Steel

Please note the Newel posts add approximately 25mm to the overall width of the staircase.


Price: £400.00 (Excluding VAT at 20%)

European Style Handrail to the Left hand side

European Style Handrail to the Left hand side

Ref: oak40hr-lh

On the Oak 40 Spacesaver The European Style handrail is Optional.

This option is for the left hand side if you are going up the staircase


Please note this can only be ordered when ordering a Oak 40 Spacesaver

Specification
Newel posts - American White Oak
Handrail - American White Oak
Balusters - Stainless Steel

Please note the Newel posts add approximately 25mm to the overall width of the staircase.


Price: £400.00 (Excluding VAT at 20%)

Oak Wall Handrail in a Box Set Chrome

Oak Wall Handrail in a Box Set Chrome

Ref: RBO

Oak Wall handrail in a Box Set with Chrome Fittings


The Pack contains
2 End Caps
3 Intermediate connectors
4 No 1 Metre sections of handrail.
5 Patrices

The handrail is Pre-finished

Sale Was £176 + VAT Now Only 129.99 + VAT


Price: £129.99 (Excluding VAT at 20%)

Fusion White Oak Wall handrail Kit

Fusion White Oak Wall handrail Kit

Ref: KIT02

Kit02 Fusion White Oak Wall Handrail Kit

3 X 1.2 metre lengths of White Oak RHR Handrail
4 X Brushed Nickel Wall Handrail Connectors
2 X Brushed Nickel Handrail End Caps
Fitting Instructions

Suitable for handrail runs upto 3.6 metres

Superb handrail kit with low shipping costs.
REDUCED - ONLY £122.58 + VAT


Price: £124.85 (Excluding VAT at 20%)

People who bought this also bought:

White Oak Newel Base 700
Fusion White Oak Baserail section SBR3600WO
Side View

Side View

This shows you a typical side view for a space saver staircase.
Building Regulations

Building Regulations

The Spacesaver staircases we produce are designed to meet the UK buiding regulations Part K sections 1.22 to 1.24 for Alternating tread Staircases.

Building Regulations Document K

As we only supply the staircase the responsability for meeting the other requirments lies with the customer.

A few of the other general requirments with Alternating Tread staircases are :-
1. The staircase must have handrails to Both Sides.
2. The Treads must have slip resistant surfaces.
3. A Alternating Tread Staircase should only be used if there is insufficient room for a normal staircase.
4. A Alternating Tread Staircase should only be used in a Loft conversion where the staircase serves only 1 habitable room, togerther with if desired a bathroom and/or WC. This WC must not be the only WC in the dwelling.

Due to the design and pitch of alternating tread staircases the user relies on familiarity together with regular use for reasonable safety.

Please note when ordering your Spacesaver staircase that this staircase is to be tailor made to your specific sizes and has no value to anyone else but yourself, due to the staircase being a purpose made item we cannot offer a refund.

Whats it like to walk up a Spacesaver Staircase ?
