Beech 40 Spacesaver

Ordering your Space saver staircase online

If you require any assistance when ordering your staircase you can contact us on 01952 608853.

From £1050 Excluding VAT and Delivery

Beech 40 Spacesaver 12 Risers

Beech 40 Spacesaver 12 Risers

Ref: BEECH4012

Beech 40 Spacesaver Staircase.

This staircase will have 12 risers, the going dimension for this staircase is 1352mm.
Specification
Strings 32 - 40mm Beech
Treads 40mm Beech
Risers 12mm Beech faced MDF

When ordering please select your rise height you can choose a height between 2300 and 2640mm
The Rise is the Floor to floor Height.

You can also select your width.

Typical delivery time on this is 3 weeks.

This staircase is made to the requirments set out in the UK Building Regulations document K for Alternating Tread Staircases.

Note - Please Note Treads on Alternating Tread Staircases require a Anti Slip Resistant Surface applying following installation - The Staircase is Not Supplied with any Anti Slip material and it is the responsability of the client to ensure this is carried out. Recomendations can be found in Document BS EN-15644 2008.

Price: £1,050.00 (Excluding VAT at 20%)

OUT OF STOCK

CATALOG SUSPENDED


Beech 40 Spacesaver 13 Risers

Beech 40 Spacesaver 13 Risers

Ref: BEECH4013

Beech 40 Spacesaver Staircase.

This staircase will have 13 risers, the going dimension for this staircase is 1462mm.
Specification
Strings 32 - 40mm Beech
Treads 40mm Beech
Risers 12mm Beech faced MDF

When ordering please select your rise height you can choose a height between 2500 and 2860mm
The Rise is the Floor to floor Height.

You can also select your width.

Typical delivery time on this is 3 weeks.

This staircase is made to the requirments set out in the UK Building Regulations document K for Alternating Tread Staircases.

Note - Please Note Treads on Alternating Tread Staircases require a Anti Slip Resistant Surface applying following installation - The Staircase is Not Supplied with any Anti Slip material and it is the responsability of the client to ensure this is carried out. Recomendations can be found in Document BS EN-15644 2008.

Price: £1,080.00 (Excluding VAT at 20%)

OUT OF STOCK

CATALOG SUSPENDED


Beech 40 Spacesaver 14 Risers

Beech 40 Spacesaver 14 Risers

Ref: BEECH4014

Beech 40 Spacesaver Staircase.

This staircase will have 14 risers, the going dimension for this staircase is 1572mm.
Specification
Strings 32 - 40mm Beech
Treads 40mm Beech
Risers 12mm Beech faced MDF

When ordering please select your rise height you can choose a height between 2700 and 3080mm
The Rise is the Floor to floor Height.

You can also select your width.

Typical delivery time on this is 3 weeks.

This staircase is made to the requirments set out in the UK Building Regulations document K for Alternating Tread Staircases.

Note - Please Note Treads on Alternating Tread Staircases require a Anti Slip Resistant Surface applying following installation - The Staircase is Not Supplied with any Anti Slip material and it is the responsability of the client to ensure this is carried out. Recomendations can be found in Document BS EN-15644 2008.

Price: £1,110.00 (Excluding VAT at 20%)

OUT OF STOCK

CATALOG SUSPENDED


Carpet Inserts

Carpet Inserts

Ref: CARP

Carpet Inserts - This option includes recessing the treads for the carpet insert and the carpet insert, please select a colour from the list.

These are only available as an option When Purchasing a Beech 40, Birch 24 or Oak 40 Spacesaver.

The Carpet insert also acts as a Non-Slip on the tread as requested in the Building Regulations.

These colours are only a guide and cannot be classed as a acurate representation of the colour.

Price: £120.00 (Excluding VAT at 20%)

CATALOG SUSPENDED

European Style Handrail to the Right hand side

European Style Handrail to the Right hand side

Ref: BEECH40-RH-HR

On the Beech 40 Spacesaver The European Style handrail is Optional.

This option is for the right hand side if you are going up the staircase

Please note this can only be ordered when ordering a Beech 40 Spacesaver

Specification
Newel posts - Beech
Handrail - Beech
Balusters - Stainless Steel

Please note the Newel posts add approximately 25mm to the overall width of the staircase.

Price: £350.00 (Excluding VAT at 20%)

OUT OF STOCK

CATALOG SUSPENDED


European Style Handrail to the Left hand side

European Style Handrail to the Left hand side

Ref: BEECH40-LH-HR

On the Beech 40 Spacesaver The European Style handrail is Optional.

This option is for the left hand side if you are going up the staircase


Please note this can only be ordered when ordering a Beech 40 Spacesaver

Specification
Newel posts - Beech
Handrail - Beech
Balusters - Stainless Steel

Please note the Newel posts add approximately 25mm to the overall width of the staircase.

Price: £350.00 (Excluding VAT at 20%)

OUT OF STOCK

CATALOG SUSPENDED


European Style Handrail to Both Sides

European Style Handrail to Both Sides

Ref: BEECH40-LHRH-HR

This option is to have the European Style handrail to both sides going up the staircase.


Please note this can only be ordered when ordering a Beech 40 Spacesaver

Specification
Newel posts - Beech
Handrail - Beech
Balusters - Stainless Steel

Please note the Newel posts add approximately 50mm to the overall width of the staircase.

Price: £675.00 (Excluding VAT at 20%)

OUT OF STOCK

CATALOG SUSPENDED


Side View

Side View

This shows you a typical side view for a space saver staircase.
Building Regulations

Building Regulations

The Spacesaver staircases we produce are designed to meet the UK buiding regulations Part K sections 1.22 to 1.24 for Alternating tread Staircases.

Building Regulations Document K

As we only supply the staircase the responsability for meeting the other requirments lies with the customer.

A few of the other general requirments with Alternating Tread staircases are :-
1. The staircase must have handrails to Both Sides.
2. The Treads must have slip resistant surfaces.
3. A Alternating Tread Staircase should only be used if there is insufficient room for a normal staircase.
4. A Alternating Tread Staircase should only be used in a Loft conversion where the staircase serves only 1 habitable room, togerther with if desired a bathroom and/or WC. This WC must not be the only WC in the dwelling.

Due to the design and pitch of alternating tread staircases the user relies on familiarity together with regular use for reasonable safety.

Please note when ordering your Spacesaver staircase that this staircase is to be tailor made to your specific sizes and has no value to anyone else but yourself, due to the staircase being a purpose made item we cannot offer a refund.
Wall Handrails

Wall Handrails

We have a number of options for wall mounted handrails look on:-

Wall handrails

Our Workshop Facilities

Take a look at our Workshop

We use the latest in CNC technology and have one of the most advanced staircase production facilities in the country.

Beech Wall Handrail in a Box Set Chrome

Beech Wall Handrail in a Box Set Chrome

Ref: RBB

Beech Wall handrail in a Box Set with Chrome Fittings


The Pack contains
2 End Caps
3 Intermediate connectors
4 No 1 Metre sections of handrail.
5 Patrices

The handrail is Pre-finished

Reduced - Was £158.69 + VAT
Now - £99.99 + VAT


All Gone !

Price: £99.99 (Excluding VAT at 20%)

CATALOG SUSPENDED

Beech Wall Handrail in a Box Set Satin Nickel

Beech Wall Handrail in a Box Set Satin Nickel

Ref: RBBN

Beech Wall handrail in a Box Set with Satin Nickel Fittings


The Pack contains
2 End Caps
3 Intermediate connectors
4 No 1 Metre sections of handrail.
5 Patrices

The handrail is Pre-finished

(The Photo shows the handrail with Chrome fittings)
Reduced - Was £164.40 + VAT
Now - £99.99 + VAT


All Gone !

Price: £99.99 (Excluding VAT at 20%)

CATALOG SUSPENDED

Open Plan Spacesaver Staircases

Open Plan Spacesaver Staircases

We also Offer Space saver staircases with Open Risers

This image shows the Beech 40 Spacesaver with Open risers with the European Style handrail and Riser Safety Bars.

(Openplan is an option on the Oak 40 and Beech 40 Spacesavers it is an extra cost option.)

Whats it like to walk up a Spacesaver Staircase ?
